Parweld XTS163 MMA Arc Welder 230v

Parweld
SKU: xts163
8 In Stock
Regular Price £189.95 Sale Price Unit price: £0.00
Includes VAT

Parweld XTS163 MMA Arc Welder 230v

The Parweld XTS 163 is a multi-mode welding package,
The touch button interface is easy to use and ideal for harsh enviroments.
Electrodes up to 3.2mm can be used with ease.

•The use of inverter technology allows the construction of a lightweight portable MMA Inverter machine which is ideal for maintenance applications.

•DC Output
The XTS 163 has a DC output and when combined with the correct type of electrode it is suitable for welding alloy, non alloy steels, stainless steel and cast iron.
Electrodes upto 3.2mm can be used with ease.

•Tig Welding

By fitting the optional Tig torch and coupling to a suitable gas supply the XTS163 can be used for Tig welding and is suitable for welding steel and stainless steel.
Wp17v-tig-torch-4-meter Available from our online store.

•The lift arc mode limits the arc current when the tungsten touches the work piece preventing electrode damage.

•Generator Friendly
The XTS 163 is able to cope with inputs which fluctuate by +/-15% and can be used with the majority of generators.

•The machine is housed in a rugged steel case. A carry case is a available as an optional extra.

3 YEAR WARRANTY
Brand PARWELD

Product Code XTS163
Key Features

Generator Friendly • Easy Electrode Striking with Arc Force • Easy Electrode Re-striking with Hot Start • Supplied with Electrode Holder, 3m Cable, 3m Earth Lead  • Connections 35-50mm Cable plug •Over Voltage and Over Current Protection • Built in Electrode Anti Sticking • IP23S • Ideal for use with Rutile Electrodes •3 Years Return to Base Warranty

Duty Cycle

160A @ 25%

KVA

6.0

Dimensions

285mm x 120mm x 250mm

Weight

4.7 Kg

Input Power Voltage

230 V +/- 15%

Input Current

16A

Output Current Range (A)

5-160A

Insulation / Protection Class

IP23S

Standards of Conformance

ISO / IEC60974-1 ISO / IEC60974-6 RoHs Compliant

Power Factor

0.93

Efficiency %

85%

Rated Output Voltage

20.8-25.6V

No Load Power (V)

78V

Technology

Inverter
